We demonstrate GPU-accelerated modelling of ultrafast optical parametric oscillators (OPOs) via the χ⁽²⁾ nonlinear envelope equation with 1265× improvement in execution time compared with a CPU-based approach. Incorporating an adaptive step-size algorithm and absorbing boundary conditions, our model is capable of simulating OPOs containing long (>10 mm) nonlinear crystals or significant intracavity dispersion with outputs generated in less than 1 minute, allowing the investigation of systems that were previously computationally prohibitive to explore. We implement real-world parameters such as optical coatings, material absorption, and non-ideal poling domains within quasi-phase matched nonlinear crystals, producing excellent agreement with the spectral tuning behaviour and average power from a previously reported prism-based OPO. Our digital twinning approach provides a low-cost iterative development platform for ultrafast OPOs.

We demonstrate a synchronously-pumped optical parametric oscillator (OPO) with a cavity formed from high refractive index inverted prisms, also known as Brewster mirrors. Exploiting a single total internal reflection, this is the simplest device capable of deviating a laser beam by 180°. The OPO produced a chirped signal output tunable from 1060 - 1570 nm with a maximum power of 114 mW. We investigate the geometric properties of ideal and imperfect Brewster mirror prisms and find the latter can provide ∼1000× finer control of the signal wavelength when compared to cavity length tuning.

We present a fully bonded, misalignment-free, diode-pumped Yb:ceramic (Yb:Y₂O₃) oscillator producing 190-fs pulses at a repetition frequency of 2.185 GHz. Self-starting Kerr-lens-modelocked operation was obtained from both outputs of the ring cavity with an average combined output power of 14–30 mW for pump powers from 380–670 mW. The fully bonded design provided self-starting, turnkey operation, with a relative intensity noise of 0.025% from 1 Hz–1 MHz. Tuning of the pulse repetition rate over a 120 kHz range was demonstrated for a 2°C change in temperature. Chirped-pulse amplification in a semiconductor optical amplifier was shown to increase the pulse average power to 69 mW and the pulse energy (peak power) from 2.5 pJ (12 W) to 32 pJ (71 W).

We present a theoretical overview and a proposed methodology which demonstrates SLASOPS (single laser asynchronous optical sampling) as a single-laser alternative to the conventional two-laser ASOPS technique. We propose the optical and electronic setup in which SLASOPS may be achieved experimentally with a single 2-section mode-locked laser diode as the pulsed-laser source and simulate how asynchronous optical sampling is generated and detected theoretically. We highlight the technique’s ability to provide customizable scan ranges, scan rates and scan resolutions through variation of the imbalance in the interferometer arms and by tuning the repetition rate of the pulsed-laser source, which we present as optical cross-correlations between pulse pairs. We incorporate jitter into the system mathematically to assess the limitations on resolving both intensity and interferometric cross-correlation traces and to investigate the effects of averaging such traces in real-time. Analysis is then carried out on cross-correlation trace amplitude, width, and temporal positioning in order to discuss the technique’s ability for deployment in typical optical sampling applications. In particular we note SLASOPS’ ability to conduct asynchronous optical sampling using only a single laser, halving both the expense and technical requirements, doing so at megahertz scan rates, and within a spatial precision of just a few microns.

We demonstrate a synchronously-pumped optical parametric oscillator (OPO) cavity in which traditional dielectric mirrors are replaced by all-planar Brewster angle prism retroreflectors, also known as Pellin-Broca prisms. Exploiting total internal reflection, these prisms form a cavity supporting >350-fs chirped signal pulses that were externally compressible to sub-150-fs durations. This simple architecture produces wavelengths tuneable across 1100 − 1350 nm, suitable for basic multi-photon applications.

We report a 1.5-GHz Kerr-lens mode-locked (KLM) Yb:Y₂O₃ ring laser constructed by directly bonding the cavity components onto an aluminum baseplate. Stable unidirectional operation with an output power ≥10mW was obtained for pump-diode currents of 300 – 500 mA, corresponding to a total electrical power consumption of 1.5 W. After repetition rate stabilization, a comparison with a conventionally constructed identical laser showed a 50% reduction in phase noise. In free-running operation the bonded laser showed superior passive repetition rate stability. The bonding process follows an already proven integration approach in space-borne instrumentation, mapping a development pathway for KLM lasers in aerospace applications.

Fiber-feedback optical parametric oscillators (OPOs) incorporate intracavity fibers to provide a compact high-energy wavelength-tunable laser platform; however, dispersive effects can limit operation to the sub-picosecond regime. In this research article, we modeled pulse propagation through systems of cascaded fibers, incorporating SMF-28 and ultra-high numerical aperture (UHNA) fibers with complementary second-order dispersion coefficients. We found that the pulse duration upon exiting the fiber system is dominated by uncompensated third-order effects, with UHNA7 presenting the best opportunity to realise a cascaded-fiber-feedback OPO.

The Extremely Large Telescope (ELT) will address an unprecedented optical wavelength range from 370 to 2400 nm, and its high-resolution spectrograph (HIRES) will require a laser frequency comb calibrator of comparable coverage. An architecture based around a Ti:sapphire master comb in principle enables wavelengths across this range to be obtained by a combination of second- and third-order nonlinear effects. In this scheme, near-infrared wavelength coverage can be addressed by downconversion of the comb to 1600 nm using an optical parametric oscillator (OPO), followed by broadband supercontinuum generation in highly nonlinear fiber. Here we present an example of this approach in the form of a 10 GHz astrocomb comprising a Fabry–Perot-filtered supercontinuum derived from a degenerate OPO and spanning 1.15–1.80 µm. We characterize the astrocomb using Fourier-transform spectroscopy, enabling the mode orders within the filtered comb to be identified.

The future of quantum photonic technology depends on the realization of efficient sources of single photons, the ideal carriers of quantum information. Parametric downconversion (PDC) is a promising route to create highly coherent, spectrally pure single photons for quantum photonics using versatile group velocity matching (GVM) and tailored nonlinearities. However, the functionality to actively control the poling period of nonlinear crystals used in PDC is currently missing, yet would enable to dynamically modify the wavelength of single photons produced in the PDC process. Herein, a detailed GVM study is presented for functional PMN-0.38PT material which can be dynamically repolled at ambient conditions with fields as low as 0.4 kV mm⁻¹. The study reveals phase-matching conditions for spectrally pure single photon creation at 5–6 µm. Further, a practical approach is proposed for on-flight wavelength switching of the created single photons. The reported reconfigurable functionality benefits a wide range of emerging quantum-enhanced applications in the mid-IR spectral region where the choice of single photon sources is currently limited.

Stable operation of a doubly resonant femtosecond optical parametric oscillator (OPO) requires submicron matching of the OPO and pump laser cavity lengths, which is normally implemented using a dither-locking feedback scheme. Here we show that parasitic sum-frequency mixing between the pump and resonant pulses of a degenerate femtosecond OPO provides an error signal suitable for actuating the cavity length with the precision needed to maintain oscillation on a single fringe and at maximum output power. Unlike commonly used dither-locking approaches, the method introduces no modulation noise and requires no additional optical components, except for one narrowband filter. The scheme is demonstrated on a Ti:sapphire-pumped sub-40-fs PPKTP OPO, from which data are presented showing a tenfold reduction in relative intensity noise compared with dither locking.

Precision calibration of astronomical spectrographs is essential to the hunt for exoplanets, the study of cosmology and determining variation of the fundamental constants. Frequency combs ('astrocombs') can serve as real-time references, providing unprecedented accuracy and precision. Here we provide a brief overview over demonstrated astrocombs and recent advances.

Photon-pair creation through parametric downconversion underpins quantum technology for quantum sensing and imaging. Here we numerically study the creation of single photons in the near- and mid-infrared (mid-IR) regime from 1 to 13 µm in a range of novel nonlinear semiconductor and chalcopyrite materials. We identify phase-matching conditions and single out regimes in which group-velocity matching can be achieved with commercially available pump lasers. Finally, we discuss how mid-IR single photons can be detected. Using our numerical results, we identify materials and pump lasers for upconversion detection in conventional wavelength bands. Our study provides a complete recipe for mid-IR single-photon generation and detection, opening up quantum enhancements for mid-IR applications such as biomedical imaging, communication, and remote sensing.

High resolution spectroscopy enables the detection of atmospheres of exoplanets. To reach the required radial velocity precision of about 1 m/s, calibration with even more precise sources is mandatory. HIRES will employ several calibration sources, the most important ones are an Laser Frequency Comb (LFC) and Fabry-Pérots (FP). The LFC needs to be filtered with a set of FP. One possible solution is to illuminate this set of FP with a broadband light source and use them as calibrators, when they are not used for filtering the LFC. It has been demonstrated that passively-stabilized FP can perform better than 10 cm/s per night. We give an overview of the currently used FP in different surveys and compare their individual features. For the FP which may be used in HIRES we discuss different configuration. We show that the Finesse and FSR of the FP needs to be optimized with regard to the resolution of the spectrograph and we outline how we aim to fulfill the requirements of HIRES.

A multi-GHz frequency comb (astrocomb) is typically realized by filtering modes of a sub-GHz frequency comb (source comb) in a Fabry-Pérot etalon, which can lead to ambiguities in determining which subset of source comb modes has been filtered. Here we demonstrate a broadband Fourier-transform spectrometer (FTS) with a resolving power of R = 430,000 at 550 nm, and apply it to the identification of comb subsets from a filtered 1‑GHz supercontinuum. After apodization the FTS demonstrated an instrument line shape width of 1.26 GHz which enabled individual comb-line positions to be identified with an uncertainty of 17.6 MHz, a relative precision of 5 × 10⁻⁸. Correcting for air dispersion allowed the instrument to determine the comb-mode spacing to an accuracy of 300 Hz and filtered subsets of source comb modes to be uniquely distingished across the entire comb bandwidth from 550 to 900 nm. The inherently broadband design of the FTS makes it suitable in future applications for calibrating ultra-broadband astrocombs employed by instruments such as ELT HIRES.

A new regime of precision radial-velocity measurements in the search for Earth-like exoplanets is being facilitated by high-resolution spectrographs calibrated by laser frequency combs. Here we review recent advances in the development of astrocomb technology, and discuss the state of the field going forward.

The instrumentation plan for the E-ELT foresees a High Resolution Spectrograph (HIRES). Among its main goals are the detection of atmospheres of exoplanets and the determination of fundamental physical constants. For this, high radial velocity precision and accuracy are required. HIRES will be designed for maximum intrinsic stability. Systematic errors from effects like intrapixel variations or random errors like fiber noise need to be calibrated. Based on the main requirements for the calibration of HIRES, we discuss different potential calibration sources and how they can be applied. We outline the frequency calibration concept for HIRES using these sources.

Precise astronomical spectroscopy with the forthcoming E-ELT and its high resolution spectrograph HIRES will address a number of important science cases, e.g. detection of atmospheres of exoplanets. Challenging technical requirements have been identified to achieve these cases, principal among which is the goal to achieve a radial velocity precision on the order of 10 cm s^-1. HIRES will experience systematic errors like intrapixel variations and random variations like fiber noise, caused by the non-uniform illumination of the coupling fibers, with these and other systematic errors affecting the performance of the spectrograph. Here, we describe the requirements for the calibration sources which may be used for mitigating such systematic errors in HIRES. Precise wavelength calibration with wide-mode-spacing laser frequency combs (LFCs), so called astrocombs, has been demonstrated with different astronomical spectrographs. Here we present a comparison of currently used astrocombs and outline a possible solution to meet the requirements of HIRES with a single broadband astrocomb.

Recording processes and events that occur on sub-nanosecond timescales poses a difficult challenge. Conventional ultrafast imaging techniques often rely on long data collection times, which can be due to limited device sensitivity and/or the requirement of scanning the detection system to form an image. In this work, we use a single-photon avalanche detector array camera with pico-second timing accuracy to detect photons scattered by the cladding in optical fibers. We use this method to film supercontinuum generation and track a GHz pulse train in optical fibers. We also show how the limited spatial resolution of the array can be improved with computational imaging. The single-photon sensitivity of the camera and the absence of scanning the detection system results in short total acquisition times, as low as a few seconds depending on light levels. Our results allow us to calculate the group index of different wavelength bands within the supercontinuum generation process. This technology can be applied to a range of applications, e.g., the characterization of ultrafast processes, time-resolved fluorescence imaging, three-dimensional depth imaging, and tracking hidden objects around a corner.

A visible astrocomb spanning 555–890 nm has been implemented on the 10-m Southern African Large Telescope, delivering complete calibration of one channel of its high-resolution spectrograph and an accurate determination of its resolving power. A novel co-coupling method allowed simultaneous observation of on-sky, Th-Ar lamp and astrocomb channels, reducing the wavelength calibration uncertainty by a factor of two compared to that obtained using only Th-Ar lines. The excellent passive stability of the master frequency comb laser enabled broadband astrocomb generation without the need for carrier-envelope offset frequency locking, and an atomically referenced narrow linewidth diode laser provided an absolute fiducial marker for wavelength calibration. The simple astrocomb architecture enabled routine operation by non-specialists in an actual telescope environment. On-sky spectroscopy results are presented with direct calibration achieved entirely using the astrocomb.

We present preliminary results of the commissioning and testing of SALT-CRISP (SALT-Calibration Ruler for Increased Spectrograph Precision), a Laser Frequency Comb (LFC) built by Heriot-Watt University and temporarily installed at the Southern African Large Telescope (SALT). The comb feeds the High Stability mode of SALT's High Resolution Spectrograph (HRS) and fully covers the wavelength range of the red channel of the HRS: 555-890 nm. The LFC provides significantly improved wavelength calibration compared to a standard Thorium-Argon (ThAr) lamp and hence offers unprecedented opportunities to characterise the resolution, stability and radial velocity precision of the HRS. Results from this field trial will be incorporated into subsequent LFC designs.

We report on the first demonstration of absolute frequency comb metrology with an optical parametric oscillator (OPO) frequency comb. The synchronously-pumped OPO operated in the 1.5-µm spectral region and was referenced to an H-maser atomic clock. Using different techniques, we thoroughly characterized the frequency noise power spectral density (PSD) of the repetition rate f_rep, of the carrier-envelope offset frequency f_CEO, and of an optical comb line ν_N. The comb mode optical linewidth at 1557 nm was determined to be ~70 kHz for an observation time of 1 s from the measured frequency noise PSD, and was limited by the stability of the microwave frequency standard available for the stabilization of the comb repetition rate. We achieved a tight lock of the carrier envelope offset frequency with only ~300 mrad residual integrated phase noise, which makes its contribution to the optical linewidth negligible. The OPO comb was used to measure the absolute optical frequency of a near-infrared laser whose second-harmonic component was locked to the F = 2→3 transition of the ⁸⁷Rb D2 line at 780 nm, leading to a measured transition frequency of ν_Rb = 384,228,115,346 ± 16 kHz. We performed the same measurement with a commercial fiber-laser comb operating in the 1.5-µm region. Both the OPO comb and the commercial fiber comb achieved similar performance. The measurement accuracy was limited by interferometric noise in the fibered setup of the Rb-stabilized laser.

By exploiting the correlation between changes in the wavelength and the carrier-envelope offset frequency (f_CEO) of the signal pulses in a synchronously pumped optical parametric oscillator, we show that f_CEO can be stabilized indefinitely to a few megahertz in a 333 MHz repetition-rate system. Based on a position-sensitive photodiode, the technique is easily implemented, requires no nonlinear interferometry, has a wide capture range, and is compatible with feed-forward techniques that can enable f_CEO stabilization at loop bandwidths far exceeding those currently available to OPO combs.

The first generation of E-ELT instruments will include an optic-infrared High Resolution Spectrograph, conventionally indicated as EELT-HIRES, which will be capable of providing unique breakthroughs in the fields of exoplanets, star and planet formation, physics and evolution of stars and galaxies, cosmology and fundamental physics. A 2-year long phase A study for EELT-HIRES has just started and will be performed by a consortium composed of institutes and organisations from Brazil, Chile, Denmark, France, Germany, Italy, Poland, Portugal, Spain, Sweden, Switzerland and United Kingdom. In this paper we describe the science goals and the preliminary technical concept for EELT-HIRES which will be developed during the phase A, as well as its planned development and consortium organisation during the study.

We report a 333 MHz femtosecond optical parametric oscillator in which carrier-envelope offset stabilization was implemented by using a versatile locking technique that allowed the idler comb to be tuned continuously over the mid-infrared range from 1.95 to 4.0 µm. A specially designed multi-section, multi-grating, periodically poled KTP crystal provided simultaneously phase-matched parametric down-conversion and pump + idler sum-frequency generation, enabling strong heterodyne signals with the pump supercontinuum (employed for locking) to be obtained across the tuning range of the device. The idler comb offset was stabilized to a 10 MHz reference frequency with a cumulative phase noise from 1 Hz–64 kHz of <1.3 data-preserve-html-node="true" rad maintained across the entire operating range, and average idler output powers up to 50 mW.

We report the generation of transform-limited 4.3-cycle (23 fs) pulses at 1.6 µm from a degenerate doubly resonant optical parametric oscillator (OPO) pumped by a 1 GHz mode-locked Ti:sapphire laser. A 𝜒⁽²⁾ nonlinear envelope equation was used to inform the experimental implementation of intracavity group-delay dispersion compensation, resulting in resonant pulses with a 169 nm full width half-maximum spectral bandwidth, close to the bandwidth predicted by theory.

We present the design and implementation of femtosecond pulse compression at 1030 nm based on spectral broadening in single-mode fiber, followed by dispersion compensation using an optimized double-pass SF11 prism pair. The source laser produced 1030-nm 144-fs pulses which were coupled into Corning® HI 1060 fiber, whose length was chosen to be 40 cm by using a pulse propagation model based on solving the generalized nonlinear Schrödinger equation. A maximum broadening to 60-nm bandwidth was obtained, following which compression to 60 ± 3 fs duration was achieved by using a prism-pair separation of 1025 ± 5 mm.

Techniques to measure and manipulate the carrier-envelope phase within femtosecond optical parametric oscillators (OPOs) allow their outputs to be stabilized in a way that produces a frequency comb structure, potentially tunable throughout the transparency band of the gain material. In this review we describe the fundamental principles of phase control, on which the development of singly- and doubly-resonant OPO frequency combs is based. We give examples of practical embodiments of such combs, and discuss in detail several applications, including spectroscopy, metrology, quantum computation and astrophotonics.

The visible to mid-infrared coverage of femtosecond optical parametric oscillator (OPO) frequency combs makes them attractive resources for high-resolution spectroscopy and astrophotonic spectrograph calibration. Such applications require absolute traceability and wide comb-tooth spacing, attributes which until now have remained unavailable from any single OPO frequency comb. Here, we report a 1-GHz Ti:sapphire pumped OPO comb whose repetition and offset frequencies are referenced to Rb-stabilised microwave and laser oscillators respectively. This technique simultaneously achieves fully stabilized combs from both the Ti:sapphire laser and the OPO with sub-MHz comb-tooth linewidths, multi-hour locking stability and without the need for super-continuum generation.

We report a 10-GHz frequency comb generated by filtering a 333.3-MHz OPO frequency comb with a Fabry–Perot (FP) cavity, which was directly stabilized to the incident fundamental comb. This result is supported by a detailed analysis of the Vernier-effect-induced multiple peaks in the transmitted comb power as the FP cavity spacing is detuned. Modes of the generated 10-GHz comb were clearly resolved by a Fourier transform spectrometer with a spectral resolution of 830 MHz, considerably better than the Nyquist sampling limit. The potentially broad tuning range of this mode-resolved OPO frequency comb opens unique opportunities for precise frequency metrology and high-precision spectroscopy.

We present the first example of a femtosecond optical parametric oscillator frequency comb harmonically-pumped by a 333-MHz Ti:sapphire laser to achieve a stabilized signal comb at 1-GHz mode spacing in the 1.1–1.6-µm wavelength band. Simultaneous locking of the comb carrier-envelope-offset and repetition frequencies is achieved with uncertainties over 1 s of 0.27 Hz and 5 mHz respectively, which are comparable with those of 0.27 Hz and 1.5 mHz achieved for 333-MHz fundamental pumping. The phase-noise power-spectral density of the CEO frequency integrated from 1 Hz–64 kHz was 2.8 rad for the harmonic comb, 1.0 rad greater than for fundamental pumping. The results show that harmonic operation does not substantially compromise the frequency-stability of the comb, which is shown to be limited only by the Rb atomic frequency reference used.

Using a zero-offset carrier-envelope locking technique, we have synthesized an octave-spanning composite frequency comb exhibiting 132-attosecond timing jitter between the constituent pulses over a one-second observation window. In the frequency domain, this composite comb has a modal structure and coherence which are indistinguishable from those of a comb that might be produced by a hypothetical single mode locked oscillator of equivalent bandwidth. The associated phase stability enables the participating multi-color pulse sequences to be coherently combined, representing an example of multi-pulse synthesis using a femtosecond oscillator.

Various schemes allow femtosecond optical parametric oscillators to produce pulses at harmonics of their pump laser repetition frequency, each apparently offering the possibility of generating widely-spaced, tunable frequency combs. Using a 100-MHz Ti:sapphire pump laser, we have compared two alternative optical parametric oscillator architectures, both leading to 300-MHz pulses but one configured in a cavity three times shorter than the pump laser and the other in a cavity one-third longer. Heterodyne measurements between the pump and each of these two systems show that they possess different carrier-envelope offset characteristics, with implications on the coherence and stabilization of the resulting combs.

We discuss recent advances in the stabilization and application of femtosecond frequency combs based on optical parametric oscillators (OPOs) pumped by femtosecond lasers at 800 and 1060 nm. A method for locking to zero the carrier-envelope-offset of a Ti:sapphire-pumped OPO comb is described. The application of Yb:KYW-laser-pumped dual-combs for mid-infrared spectroscopy is detailed, specifically methane spectroscopy at approximately a 0.7% concentration at 1 atm.

By combining broadband common-path spectral interferometry with an iterative fitting algorithm the phase response of a liquid-crystal spatial light modulator has been characterized from 400 to 770 nm, equivalent to a frequency bandwidth of 0.36 PHz. The resulting calibration not only maps the response of the device as a function of wavelength and voltage, but also provides sufficient information to recover the thickness of the liquid-crystal cell and the wavelength dependent refractive index of the liquid-crystal. The technique has applications in amplitude and phase shaping of pulses from broadband super-continuum and optical parametric oscillator/amplifier sources.

We report a fully stabilized 1030-nm Yb-fiber frequency comb operating at a pulse repetition frequency of 375 MHz. The comb spacing was referenced to a Rb-stabilized microwave synthesizer and the comb offset was stabilized by generating a super-continuum containing a coherent component at 780.2 nm which was heterodyned with a ⁸⁷Rb-stabilized external cavity diode laser to produce a radio-frequency beat used to actuate the carrier-envelope offset frequency of the Yb-fiber laser. The two-sample frequency deviation of the locked comb was 235 kHz for an averaging time of 50 seconds, and the comb remained locked for over 60 minutes with a root mean squared deviation of 236 kHz.

The carrier-envelope-offset frequencies of the pump, signal, idler and related second-harmonic and sum-frequency mixing pulses have been locked to 0 Hz in a 20-fs-Ti:sapphire-pumped optical parametric oscillator, satisfying a critical prerequisite for broadband optical pulse synthesis. With outputs spanning 400 - 3200 nm, this result represents the broadest zero-offset comb demonstrated to date.
